Work done for protoDUNE.

Pattern recognition in ProtoDUNE: simulated raw data in 2D projections (on the left) and reconstructed separation between hadron tracks and electromagnetic activity using Convolutional Neural Network (on the right).

Event reconstruction in ProtoDUNE: raw data from 2D projections (on the left) and 3D Projection Matching Algorithm reconstruction (on the right).
The picture shows cosmic rays on top of an incoming pion from the accelator.

The CMS timing and control distribution system (TCDS).
Left: the FC7 µTCA module. Right: part of the system in CMS.

View of Medipix3 chip. Left: view of the pixel side of the native thickness chip. Middle: Through Silicon Via (TSV) processed chip. Right: chip «BGA» bottom distribution

View of a NA62 Gigatracker Module

Radiation hard bi-directional optical link. View of the serialiser-deserialiser ASIC (GBTX), the transimpedance amplifier and the optical transceiver (VTRX).

Full-size model of the CLIC vertex detector, assembled for air-cooling tests

Fine-grained hadron calorimeter beam tests for CLIC at the CERN SPS (CALICE collaboration)

Top view of the CMS open detector during LS1

CMS endcap calorimeters seen through YE2

CMS closed, ready for data taking

CMS Ready for beam pipe installation

Side A of the ATLAS cavern

Closing of the ATLAS calorimeters

Novel CO2 cooling plants installed in the CMS service area, for the new Pixel system

Turning machine for the NA62 Straw Tube Modules built by EP-DT

Magnet Safety system designed by EP-DT for the magnet system of the Compass experiment

View from below CLOUD experiment’s aerosol chamber, opened for equipment installation

Insertion of the GTK pixel detector in the NA62 beam line. It is the first detector to be cooled with microchannels embedded in a thin silicon substrate.

Microchannels etched in a silicon substrate to be used as microfluidic scintillation detectors by EP-DT

CERN logo microfabricated in the cleanroom of the EPFL Center for MicroNanoTechnology

The new ALICE-MTR gas re-circulation system developed in EP-DT, installed in the ALICE underground gas service area

NA62 Straw module ready for installation in the NA62 experimental area

Fiber winding machine constructed in EP-DT for the LHCb Upgrade Scintillating Fibre (SciFi) Tracker project. The total length of the fibres to process exceeds 10,000 km.

The LHCb Calorimeters

The LHCb Vertex Locator

Layout of the LHCb experiment

An LHCb event display

The LHCb cavern

ALICE event display of a Pb-Pb collision at 2.76A TeV




ALICE Run Control Center

The Experimental Physics (EP) Department carries out research in the field of experimental particle physics.
It aims to provide a stimulating scientific atmosphere and remains an important reference centre for the European physics community. It contributes to the education and training of young scientists.

EP is one of the largest departments at CERN, with about 500 staff members and over 300 other members of personnel: Fellows, Associates, Students and Apprentices. In addition it hosts the approximately 12,000 Users that visit CERN from their home institutes around the world to perform scientific research.
